Urban Concinnity

Year: 2017

Project type: Urban infrastructure analytical casestudy

Client: Academic project

Data of over 30 acres of land in the city of Belgaum, Karnataka. Most of the data was collected manually, and the rest was collected from the city corporation and development office

jpeg-optimizer_1. city map.png
Heading 5

Project brief

Belgaum  City is a moderately populated city in Karnataka. This project aimed to observe and determine urban cracks, and unused spaces and a study of the local, communal, and social structure amongst the people. Identification of issues and plausible solutions through design.

Built Vs Open

Land Use

jpeg-optimizer_3. BUILT VS OPEN.png
jpeg-optimizer_4. LAND USE.png
jpeg-optimizer_13. spaces data sheet template.png

Private vs Public Space

jpeg-optimizer_6. ROOF TYPOLOGY.png

Roof Typology

Parking Pattern

Occupation

jpeg-optimizer_12. parking data sheet template.png
jpeg-optimizer_19. occupation.png

Road pattern

Community Density

jpeg-optimizer_11. STREET PATTERN.png
jpeg-optimizer_18. communitty data sheet.png
key plan (1).png

The highlighted zone was observed and documented. Identifying the major concerns and potential the site had.

movementstructure copy.JPG

Traffic caused due to bottle-neck during closing of railway-gate.

bottle neck.jpg

Clogged with vehicles at the peak hours.
Majorly vehicles - goods carrying vehicles to off-load goods.

2 (3).JPG
2 (3).JPG

Plausible solution - provision of goods-offloading nodes, also can be used as bus stops. This can reduce the traffic by 23%. .

Open-pocket

map open spaces (1).png

Present Usage

open space 2 (1).png

Present Usage of these space

  • Dumping ground

  • Non-resident vehicular parking

  • Space for stray animals

Site-potential

open 1 (1).png

Provision for systematic parking system.
Providing seating and community spaces

OPEN SPACE SHEET copy (1).png
site pic (1).png

Present Usage

site 2 (1).png
